WHAT THE FOCUSSHIFTER RD-14 CAN DO FOR YOU:
The third dimension (3D) is not always the nonplus ultra. The FOCUSSHIFTER-14 deliberately takes a (half) step backwards to significantly increase the range of applications for you as a machine builder or integrator in the fields of e-mobility, solar/photovoltaics, and electronics/IT: With the FOCUSSHIFTER-14, you can clean component contact surfaces of paint, oxide layers, oil or insulation, cut flexible PCBs, glass displays or polarisation foils, texturise or structure a wide variety of surfaces and connect components. Finally, the FOCUSSHIFTER-14 cuts an excellent figure in the resistance trimming of 5G antennas. The highlight: all this is done in two and a half dimensions – 2.5D.
This is achieved automatically by the FOCUSSHIFTER-14 shifting the focus – generated by the f-theta lens – either downwards or upwards. This combination forms the basis for you to be able to process different height levels of the same workpiece – qualitatively and quantitatively of high quality.
When things have to go fast
Versatile use
What you can rely on with RAYLASE:
Usability, quality, and productivity are our core issues. That is why the development, production, and functional testing of our high-quality laser applications for almost all industries are carried out exclusively in our in-house laboratories and production facilities. Fast services and professional maintenance are ensured by our worldwide support network.
Flexibility you can see:
Removing oxides, lacquers, rust, or insulation is just as efficient and precise with the FOCUSSHIFTER-14 as texturing or joining complex and, of course, simple component geometries. The highly dynamic focusing axis with Moving coil drive ensures maximum dynamics and speed and thus guarantees the best results in demanding processes. Your benefit: a very good Overall Equipment Effectiveness (OEE) in your production.
And in case you want to machine three-dimensional, inclined, spherical, or curved planes, this can also be reliably realised by a combination of FOCUSSHIFTER-14 and suitable software.
How we define quality assurance:
For you as a machine builder or integrator, the high technical level of a laser beam deflection unit like the FOCUSSHIFTER-14 is not everything. A practicable technology for you – and all industries in which laser technology is used – is characterised above all by uncomplicated implementation in existing designs. To make this possible, the FOCUSSHIFTER-14 has many threaded and pin holes – on the side, at the bottom and even on the beam entry side.
Using the appropriate software, your laser job can be set up on the camera image of the workpiece and an automatic position correction can be carried out in production – together with an archiving function, features that speak for optimal quality assurance. It goes without saying that you can expect the best quality results from optional image viewing and processing software, regardless of whether it comes from us or a third-party supplier. Just like the fact that the FOCUSSHIFTER-14 is IP64 rated.
Two different control protocols on one connector and a separate power supply make the FOCUSSHIFTER-14 quickly ready for use.
