UNIVERSAL CONTROL WITH 20 BIT POSITION RESOLUTION AND 10 μs STEP PERIOD
The SP-ICE-3 control card is the universal solution for every laser system with deflection units. With its multiple individually configurable ports it fits everywhere, even at highly specific requirements. Thanks to the .NET programming environment and the flexibility of the SP-ICE-3 control card a broad variety of applications can be solved quickly.
The SP-ICE-3 controls up to 2 deflection units via the SL2-100 or RL3-100 protocol with 20 bit position resolution and 10 μs step period. It can log up to 24 million measurements from the deflection unit. This allows for system optimization during development an continuous monitoring during operation.
With its 1 GB RAM and a 32 GB MicroSD-card users may upload and store numerous highly complex laser programs to the card at once. Five configurable I/O-ports with up to 24 bit, two quadrature decoders, a USB 2.0 and a RS232 interface make the SP-ICE-3 your central control unit for laser processes.
SP-ICE-3 client software and firmware installation/update via:
RAYLASE PRODUCT INSTALLER
